0050841035 Connector Fan 3 pin OEM

The Molex 0050841035 (also known as 50-84-1035) is a 3-pin power plug from the MLX 42021 series, designed for reliable power connections in various devices. With a 6.35 mm pitch and the ability to handle up to 20 A at 600 V, it is ideal for connecting fans, pumps, and other high-power components. Key Features: Connection Type: Plug for wire-to-board and wire-to-wire connections. Number of Contacts: 3 (single row). Contact Pitch: 6.35 mm. Housing Material: Nylon (PA66) with UL 94V-0 flammability rating. Operating Temperature Range: -55 °C to +105 °C. Current Rating: Up to 20 A. Voltage Rating: Up to 600 V. Contact Type: Crimp. Mounting Style: Through-hole. This connector features a mechanical latch to prevent accidental disconnection and a polarized design to ensure correct mating. It is widely used in automotive, medical, telecommunications, and industrial equipment. The MLX series from Molex is known for its durability and compatibility with various contact types and assembly tools.
