Kromschroeder DG500UG-4K2 (84447041) gas pressure switch

Kromshroeder 84447041 DG500UG-4K2 differential pressure switch designed to monitor pressure changes in gases or air, regardless of whether it is increasing or decreasing. Krom schroder DG500UG-4K2 84447041 gas pressure sensors respond to any pressure deviations from the setpoint. When the set pressure is reached, a microswitch with a switching contact is switched on. The trigger level is adjusted using a handwheel. Krom schroder DG500UG-4K2 84447041 pressure switch technical data Gas type: natural gas, town gas, LPG (gaseous), flue gas, biogas (max. 0.1 %-by-vol. H2S) and air Maximum medium and ambient temperatures: -20 to +80°C Long-term use in the upper ambient temperature range accelerates the ageing of the elastomer materials and reduces the service life Storage temperature: -20 to +40°C Diaphragm pressure switch, silicone-free Diaphragm: NBR. Housing: glass fibre reinforced PBT plastic with low gas release Lower housing section: AlSi 12 Enclosure: IP 54 or IP 65 Safety class: 1 Line diameter: 0.5 to 1.8 mm (AWG 24 to AWG 13) Line entrance: M16 x 1.5, clamping range: diameters of 4 to 10 mm Electrical connection type: screw terminals Weight: 0,321 kg
