Kromschroeder DL10K-3W (84444800) air pressure switch

Kromschroeder DL10K-3W 84444800 differential pressure switch ensures precise monitoring and adjustment of pressure levels within systems handling air or flue gases. It offers versatility in controlling various pressure conditions, contributing to the safe and efficient operation of equipment such as boilers, ventilation systems, and other industrial applications. Krom schroder 84444800 DL10K-3W air pressure switch technical data Adjusting range: 1.0-10 mbar, can be used as ''special-design pressure switch'' Gas type: air or flue gas, no flammable gases, no aggressive gases Housing with tube connection and hand wheel Electrical connection via screw terminals Z-angle bracket Micro switch to EN 61058-1 Safety class II to VDE 0106-1 Maximum medium and ambient temperatures: -20 to +80°C (-4 to +176°F) Diaphragm pressure switch, tempered LSR diaphragm system Housing: glass fibre reinforced PBT plastic with low gas release Weight: 0,054 kg Cover screw: 65 Ncm Strain relief facility: 65 Ncm Kromschroder DL10K-3W 84444800 pressure switch certification 1. Kromschroder DL10K-3W 84444800 air pressure switch, identified by product ID No. CE-0085AP0466, is compliant with several Directives and Standards, including: -          Directive 2009/142/EC – Gas Appliances Directive (GAD), valid until 20 April 2018. -          Directive 2014/35/EU – Low Voltage Directive (LVD). -          Regulation (EU) 2016/426 – Gas Appliances Regulation (GAR), effective from 21 April 2018. 2. This pressure switch conforms to the requirements set forth in Standards EN 13611:2015+AC:2016 and EN 1854:2010. 3. The specific Kromschroder DL10K-3W 84444800 differential pressure switch corresponds to the tested type sample and is subject to ongoing production surveillance procedures outlined in: -          Directive 2009/142/EC Annex II paragraph. -          Regulation (EU) 2016/426 Annex III paragraph 3.
