Kromschroeder KFM160RB100 (03200124) pressure gauge

Indicating manometer Kromschroder KFM160RB100, 03200124 is a high-precision measuring instrument with a diaphragm element, designed for visual monitoring of static pressure of natural gas, LPG (gaseous phase) or clean air in industrial gas supply and heating systems. The model with a 100 mm dial diameter and range 0–160 mbar is designed for low pressure measurement and is most often used on burner gas trains for precise adjustment and visual monitoring of gas pressure before combustion. Failure of the standard manometer (stuck pointer, loss of seal, inaccurate readings) prevents correct burner adjustment, leading to fuel overconsumption, unstable combustion and emergency shutdowns. Technical specifications: Parameter Value; Part numbers 03200124, KFM160RB100, 624.466.002; Manufacturer Kromschroder / Honeywell (Germany); Instrument type Indicating manometer (indication only); Working medium Natural gas, LPG (propane-butane), biogas, clean dry air; Measuring range 0 – 160 mbar (0 – 0.16 bar); Visible dial diameter 100 mm; Accuracy (class) 1.6 (per EN 837-3); Measurement accuracy deviation ±0.6%; Connection Brass, thread G ½" B; Mounting position Horizontal; Protection degree IP54 (dust and splash proof); Housing material Stainless steel; Medium temperature from -20°C to +60°C; Dimensions (L x W x H) 140 x 100 x 49 mm; Weight 0.57 kg; Service life 10 years. Key advantages: High-precision low pressure measurement: Thanks to the diaphragm measuring element, this manometer provides high accuracy (class 1.6) precisely in the low range 0-160 mbar, where standard Bourdon tube manometers (RFM) are ineffective. Overload protection: The measuring system is designed to withstand short-term pressure peaks.
