hp-Technik PON4-D-R-4-25 oil pump

The hp-Technik PON4-D-R-4-25 is a compact gear pump designed for transferring diesel, gasoline, kerosene, and heating oil. It features an integrated pressure relief valve, filter, and bypass for consistent and reliable operation in domestic and industrial burner systems. hp-Technik PON4-D-R-4-25 pump technical data: Flow rate: up to 320 liters per hour Maximum pressure: 40 bar Rotation direction: clockwise (type D) Speed: 1400–2800 RPM (max. 3500 RPM) Torque: 1.2 Nm Shaft diameter: 12 mm Connections: Suction and return lines: ½ inch Nozzle outlet: ¼ inch Pressure gauge port: ⅛ inch Vacuum gauge port: ¼ inch Weight: 5 kg The pump is suitable for heating systems and small burner applications, ensuring dependable fuel supply even under demanding conditions.
