Honeywell VQ440MA1006 gas valve DN40

Honeywell VQ440MA1006 Class "A" gas valve control gas flow in burners, boilers, and furnaces. Honeywell VQ440MA 1006 compact gas unit support accessories like position indicators and pressure switches. Complying with EN 161, they feature flanged connections from 1/2" to 2" and include two safety valves: V1 (fast opening) and V2 (adjustable opening). Honeywell VQ440MA1006 CVI valve technical data: Maximum operating pressure: 360 mbar Pipe connections comply with the requirements of group 2 of the EN 161 standard Electrical connections: standard connector corresponding to the PG11 connector on the main gas valves and additional valves Ambient temperature range: -15 ... 60 °C Coil insulation: insulation material conforming to Class F Body material: Aluminum alloy, injection molding Closing spring: AISI 302 steel Valve plunger: chrome-plated Fe 360B steel sliding on an anti-friction bearing Seals and gaskets: hydrocarbon-resistant NBR rubber Number of cycles: 300000 Closing time: < 1 sec Maximum response frequency: 1 cycle per minute Duty cycle: coils are suitable for continuous excitation
