Honeywell VE4010B1062 solenoid valve DN10

Honeywell VE4010B1062 gas control block used for control and regulation of gaseous fluids in gas power burners, atmospheric gas boilers, melting furnaces, incinerators and other gas consuming appliances. Honeywell VE4010B 1062 combined gas valve technical data: Pipe sizes: Inlet and outlet 3/8” up to 2” internal parallel pipe thread according to ISO 7-1 Mounting and orientation: The valve may be assembled on the pipeline within plus or minus 90 degrees of the vertical axis and 30 cm. air space around the coil assy Torsion and bending stress: Pipe connections meet group 2, according to EN161 requirements Ambient temperature range: -15 ... 60 °C Electrical connection: Plug connection according to PG11 Optional: Male DIN plug connector according to ISO4400 Coil insulation solenoid valves: Insulation material according to class F Valve body: Aluminum alloy die-cast Bottom plug: Rp 1/4” for Closed Position Indication (CPI) switch Strainer: AISI 303 steel Closing spring: AISI 302 steel Valve plunger: Chrome plated Fe 360B steel sliding on anti-friction bearing Seals and gaskets: Hydrocarbon resistant NBR rubber type Optional: Viton rubber type Rated Voltage (Vac): 110 Connect (inch): 3/8 DN: 10 Maximum Operating Pressure (mbar): 360 Power Cons. (W): 14 Enclosure: IP65 Weight (kg): 1.1 Honeywell VE4010B 1062 CVI valve standards and approvals: Honeywell VE4010 B 1062 gas solenoid valve in accordance with EN161 standards. Honeywell VE4010B1062 compact gas unit conform to the following EC directives: Gas Appliance Directive (90/396/EEC) PIN: CE-0063AP3075/1 Low Voltage Directive (73/23/EEC) Electro Magnetic Compatibility Directive (89/336/EEC)
