Honeywell R4343E1014 flame switch

The Honeywell R4343E1014 pressure switch is an advanced control device that works in conjunction with compatible sensors to detect and signal the presence or absence of flame or ultraviolet radiation. Honeywell R4343E1014 differential pressure switch technical data: Two models available to operate at 115Vac, 230Vac (+ 10 % to - 15%), 50/60 Hz. Contact: 2 isolated DPDT contacts. Rating: 2A at 0.65 power factor. Ambient temperature limits: -10 to + 60 °C. Maximum relative humidity: 90% RH at + 40 ° C. Degree of protection: IP40. Flame failure response time. Less than one second (standard models). Other timings available on request. Classification: OOCRXO. The performance of the Honeywell R4343E1014 pressure switch heavily depends on the proper installation of the flame sensor. To achieve optimal functionality, it is crucial to follow the burner/boiler manufacturer’s guidelines and the specifications provided with the sensor.
