Honeywell R4343E1006 flame switch

The Honeywell R4343E1006 pressure switch is an advanced control device that works in conjunction with compatible sensors to detect and signal the presence or absence of flame or ultraviolet radiation. Flame signal monitoring – an integrated socket for the flame current meter allows real-time tracking of signal strength, ensuring system reliability. Smart design – the plug-in module is securely attached to a base designed for surface mounting. The housing meets the IP40 standard, providing adequate protection. The performance of the Honeywell R4343E1006 pressure switch heavily depends on the proper installation of the flame sensor. To achieve optimal functionality, it is crucial to follow the burner/boiler manufacturer’s guidelines and the specifications provided with the sensor. Honeywell R4343E1006 differential pressure switch technical data: Two models available to operate at 115Vac, 230Vac (+ 10 % to - 15%), 50/60 Hz. Contact: 2 isolated DPDT contacts. Rating: 2A at 0.65 power factor. Ambient temperature limits: -10 to + 60 °C. Maximum relative humidity: 90% RH at + 40 ° C. Degree of protection: IP40. Flame failure response time. Less than one second (standard models). Other timings available on request. Classification: OOCRXO. For use with UV power tube flame detectors.
