Honeywell LKS160-36 (B5-5S4) actuator

The Honeywell LKS160-36 (B5-5S4) actuator is designed for installation on multistage or modulating liquid fuel burners in a fully closed position. The Conectron 78-LKS160-36 servo motor is highly reliable and efficient, providing precise control and stable burner operation. Its use makes it possible to increase the efficiency of heating systems, reduce fuel consumption and reduce harmful emissions into the environment. Thanks to modern technologies and high-quality materials, the Conectron Honeywell LKS160-36 (B5-5S4) servomotor provides a long service life and excellent functioning in various operating conditions. Technical data of the Honeywell 78-LKS160-36 actuator Power supply: 230 V Opening time at 90 °: 5 seconds Torque: 2.5 N*m Dust and moisture protection class: IP 44 Drive motor: reversible synchronous motor Setting the switching point: stepless adjustment of the cams, cams with lever or spindle drive; when driven from a spindle - with a superimposed scale Position indicator: scale Connection system: terminal blocks Gear transmission: cylindrical transmission, maintenance-free Drive shaft: steel Installation and fastening: it is attached from the inside using through holes with M 5 thread Safety class: II VDE 0631 Power consumption: approximately 4 VA Duty cycle: depending on the engine, from 50 to 70% in 2 minutes Interference suppression: N (according to VDE 0785) Operating angle: maximum 90° Mounting position: any Certificates of the Conectron LKS160-36 (B5-5S4) servo motor According to the standards of the European Union 73/23/EU and 93/68/EU, the Honeywell 78-LKS160-36 servo motor complies with the following standards: EN 60730-1:1991 A1 and A11:1991 EN 60730-2-5:1991
