Danfoss 070-3354 RSA60 oil pump

Danfoss 070-3354 RSA60 oil pumps designed for small and medium domestic burners with a fuel flow capacity of up to 255 liters per hour. Equipped with a built-in pressure regulator with shut-off functionality and a special spring, they suitable for use as either transport or supply pumps. Danfoss 070-3354 RSA60 oil burner pumps are ideal for transferring light fuels, including kerosene. They offer the flexibility of single or two-pipe operation but are configured for one fixed pressure level. Danfoss RSA60 070-3354 gear pumps also feature an integrated ring filter, making them versatile for use as either transport or feed pumps. Danfoss RSA60 070-3354 gear pump technical data: Viscosity range (in the suction line): 1.3-75cSt(mm2/s) Filter area / section: 75/150 cm2/microns Pressure range: 5.5-21 bar Factory settings: 7+-1 bar Max. pressure in the suction/return line: 4 bar Shaft rotation speed: 1400-3450 min Max. starting torque: 0.24 Nm Ambient temperature: -20 to +70 °C Storage temperature: -25 to +70 °C Fuel temperature: -10 to +70 °C Shaft: EN225
