Brahma 18200452 ST09 M/1 G1/8 CH15 temperature sensor

Brahma NTC107 temperature sensor — immersion temperature sensor designed to control the temperature of the heat transfer fluid in heating equipment. Used in floor-standing and wall-mounted boilers, indirect heating tanks, storage and instantaneous water heaters for accurate temperature measurement and correct operation of automation. The sensor transmits data to the control board, ensuring stable operation of the heating system and protection of equipment from overheating. Advantages: Original Brahma temperature sensor Manufacturer part number: 18200452 Internal part number: 246.220.107 High temperature measurement accuracy Reliable NTC element Fast response Easy installation and replacement Long service life Technical specifications: Type: immersion temperature sensor Model: ST09 M1 Connection: G1/8 Version: CH15 Connector: modular green connector Dimensions: 40 × 20 × 15 mm Net weight: 0.015 kg Gross weight: 0.020 kg Application: Suitable for: floor-standing boilers wall-mounted boilers with hot water tank storage water heaters instantaneous water heaters Used in heating and DHW systems for liquid temperature control. Original Brahma NTC107 sensor ensures stable and safe operation of heating equipment.
