Baltur cable for FC13

This cable is part of the Baltur range for the FC13. Cables of this type carry low-voltage signals and mains supply between the burner control board and its connected components — such as the gas valve, ignition transformer, air pressure switch, and modulating actuator. Unlike generic wiring, these cables are matched by their connector series, pin count, pitch and keying rather than by the function they serve; a cable that fits the connector will work regardless of which signals pass through it. Selection of a replacement cable is based on the connector type and pin count, the conductor cross-section (which must be adequate for the current carried), the insulation temperature class (typically suitable for the ambient conditions near a burner), and the length. The terminal type — female sockets, male pins, or ring terminals — must also match the mating connector. A poor contact in any connector can reproduce almost any electrical fault symptom (lockout, erratic modulation, false flame signal), so connectors are a routine suspect during fault finding on burners of this class. When sourcing a cable for the FC13, verify that the replacement matches the original connector specifications exactly.
