Attuatore Honeywell MT4002B1008

Honeywell MT4002B1008 actuator is used for air dampers in oil burners. Includes relay for 2-wire connection to thermostat. Voltage: 220...240 V AC, 50/60 Hz. Ambient temperature: -15...60°C. Relative humidity: 0-90% at 40°C, non-condensing. Rated torque: max. 3 Nm. Running time over 90 degrees: 6 sec at 50 Hz. At 60 Hz approximately 20% less. Maximum adjustable stroke: 0-160 degrees. Protection class: IP40. Minimum camshaft step: 2. Direction of rotation: Right.
